SUC207 35MM Stainless Steel Insert Bearing 35mm Bore Ball Bearings

Brand Name : NTN

Model Number : SUC205

Certification : ISO : 9001

Place of Origin : CHINA

MOQ : 1

Price : US$ 0.1-50 /pcs

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10000/pcs/month

Delivery Time : 3-15 days

Packaging Details : Single box

Inside diameter : 35 MM

Outside diameter : 72 MM

Thickness/width : 42.9 MM

Basic dynamic load rating : 21.6kn

Basic static load rating : 13.7kN

Weight : 0.5 kg

Category : Stainless steel insert bearings

Contact Now

SUC207 35MM Stainless Steel Insert Bearing 35mm Bore Ball Bearings

The stainless steel bearings not only have the characteristics of the ordinary bearings: Low vibration, low noise, high precision rotating, lower friction torque and high speed running but also have its special usage function.

The range of application is wide:

It is an acid-proof and alkali-proof
It can work in corrosion medium such as sea water, river aqua, distilled water, sparse nitric acid, maritime climate, steam and so on
It can work in the high or low temperature environment

SUC 207, SUC Stainless Steel Bearing Inserts :

Balls & Rings - 440 Stainless Steel
Seal - Silicone Rubber
Seal Frame & Slinger - 302 Stainless Steel
Retainer - 302 Stainless Steel
Set Screws - 304 Stainless Steel
Locking Collar (SNA only) - 304 Stainless Steel
Lubrication - H-1 Food Grade Grease

The details of SUC207 35MM Stainless Steel Insert Bearing 35mm Bore Ball Bearings :

d - Bore Dia. of Bearing	1 7/16 Inch
D - Dimension	2.8346 Inch72.0 mm
Bi - Dimension	1.6890 Inch42.9 mm
Be - Dimension	0.7874 Inch20.0 mm
N - Dimension	0.6890 Inch17.5 mm
M - Dimension	1.0000 Inch25.4 mm
G - Dimension	0.2559 Inch6.5 mm
Ds - Dimension	5/16-24UNF Inch
H - Dimension	0.6890 Inch17.5 mm
K - Dimension	2.1890 Inch55.6 mm
Basic Load Rating	4.930 lb
Basic Static Load Rating	2.780 lb
Weight	0.99 lb

Below is the picturer of SUC207 35MM Stainless Steel Insert Bearing 35mm Bore Ball Bearings :

SUC207 35MM Stainless Steel Insert Bearing 35mm Bore Ball Bearings
